Pipe Threads

G 1/8, 1/4 Parallel (F)

- Standard

BSPTr./NPT

- Optional

Body Material

Zinc Alloy die-cast

Filter Element Size

5, 25, 40 micron.

Filter Element Material

Plastic (Polypropylene)

- Standard

Sintered Bronze

- Optional

Bowl Material

Transparent Polycarbonate

- Standard

Metal Zinc diecast

- Optional

Maximum Inlet Pressure

with P.C. Bowl Manual and Automatic Drain

150 psig (10.5 bar)

with Metal Bowl Manual Drain

250 psig (17.5 bar)

with Metal Bowl Automatic Drain

150 psig (10.5 bar)

Max. Operating Temp. (ambient)

with PC Bowl: 50℃ (125℉)

with Metal Bowl: 80℃ (175℉)

Drain

Manual - Standard

Automatic - Optional (operates only on flow change)

Regulator Type

Relieving - Standard

Non-Relieving  - Optional

Pressure Adjustment

Non-rising plastic knob

Regulated secondary outlet pressure (Spring Range) and recommended pressure gauge ranges available (in kg/cm2)

Spring Range

Gauge Range

1-10 psi (0.07 to 0.70 bar)

0-35 psi (0 to 2.5 bar)

3-30 psi (0.21 to 2.10 bar)

0-35 psi (0 - 25 bar)

5-50 psi (0.35 to 3.50 bar)

0-60 psi (0 to 4.0 bar)

10-100 psi (0.70 to 7.0 bar)

0-150 psi (0 to 10.0 bar)

15-150 psi (1.00 to 10.0 bar)

0-220 psi (0 to 16.0 bar)

Std. Nominal flow at 10 bar (150 PSI) Inlet pressure 6 bar (87 PSI ) set pessure and a drop of 1 bar (14.5 PSI) from set

G 1/8"

18 scfm (8.4 dm3/sec) CV (0.33)

G 1/4"

19 scfm (9.0 dm3/sec) CV (0.35)

Gauge size

40 mm (Dial Size)

Gauge Port size

Rc 1/8 BSPTr.

Gauge connection

Back

Mounting Bracket

Optional

Panel mounting

Standard - Available

Pressure Gauge (scale)

Kg/cm2 (PSI)

- Standard (For Domestic Market)

Bar (PSI)

- Standard (Export)
