Measurement Range

1-25% vol. O2

Maximum Overload

30% vol. O2

Output Signal

0.10 ± 0.02 mA in Air

Response Time (T90)

<15 Seconds

Zero Current (Offset)

<0.6% vol. O2

Linearity

Can be considered linear in many cases.

Recommended Load Resistor

100 ?

Casing Material

ABS

Weight

<16 g

Orientation Sensitivity

<0.2% vol. O2 equivalent

Operating Temperature Range

-20°C to +50°C (up to 3 months continuous across RH range)

Recommended Storage Temp

0°C to 20°C

Thermal Transient(Temp. plunge +22°C to -20°C)

<23.5% vol. O2

Operating Pressure Range

Atmospheric ± 20%

Pressure Coefficient

<0.02% signal/mbar

Pressure Transient(60 cm H2
O step change)

<200% signal change

Relative Humidity Range

(at 0°C to 20°C)

Continuous

5 to 95%RH non-condensing

Short Term

0 to 99%RH non-condensing

Long Term Output Drift

<2% signal/month Typically <5% over operating life

Expected Operating Life

Minimum 24 months in air

Storage Life

6 months in original packaging
24 months from date of despatch
