MEASUREMENT

Operating Principle

Partial pressure electrochemical

Output

9 mV to 13 mV in 210 mBar O2

Measurement Range

0 mBar to 1500 mBar O2

Response Time (T )

<15 s (air to 100% O)

Baseline Offset

<200 μV

Linearity

Linear 0% to 100% O2

ELECTRICAL

Temperature Compensation

Partial compensation for Teledyne T-7 equivalence

External Load Resistor

10 kΩ min.

Connector

UK Data Socket AMP (P/N 520257-2)

MECHANICAL

Housing Material

White ABS

Weight

42 g (nominal)

Orientation

Any

ENVIRONMENTAL

Typical Applications

Critical care anesthesia

Operating Temperature Range

-20°C to +50°C

Operating Pressure Range

0.5 Bar to 2.0 Bar

Operating Humidity Range

0% to 99% RH non- condensing

LIFETIME

Long-Term Ouput Drift in 100% O2

< 5% signal loss/year

Recommended  Storage Temperature

-10°C to 40°C (short excursions to 50°C allowed)

Expected Operating Life:
20°C
40°C

1.5 x 106 % O2 hours
0.8 x 106 % O2 hours

Packaging

Sealed blister

Standard Warranty

13 months from date of despatch
(This amounts to a variation of condition 6 of our standard terms and conditions which otherwise apply)
