MEASUREMENT

Operating Principle

Partial pressure electrochemical

Output

9 mV to 13 mV in 210 mBar O?

Measurement Range

0 mBar to 1500 mBar O?

Response Time (T90)

<15 s (air to 100% O?)

Baseline Offset

<200 μV

Linearity

Linear 0% to 100% O?

ELECTRICAL

Temperature Compensation

<2% O? equivalent (0°C to 40°C)

External Load Resistor

10 kΩ minimum

Connector

3-pin Molex Header:(Molex 22-29-2031)

Recommended Mating Part

Molex Housing:
(Molex 22-01-2035)
Molex Crimp Terminals
(Molex 08-45-0110)

MECHANICAL

Housing Material

White ABS

Weight

39 g (nominal)

Orientation

Any

ENVIRONMENTAL

Typical Applications

Critical care anesthesia

Operating Temperature Range

—20°C to +50°C

Operating Pressure Range

0.5 Bar to 2.0 Bar

Operating Humidity Range

0% to 99% RH noncondensing

LIFETIME

Long-Term Ouput Drift in 100% O?

< 5% signal loss/year

Recommended Storage Temperature

—10°C to +40°C

Expected Operating Life:
@ 20°C
@ 40°C

1.5 x 10 6 % O? hours
0.8 x 10 6 % O? hours
