General

Weight

0.25 kg (0.55 lbs)

Installation orientation

Unrestricted

Storage ambient temperature range

-40 to 100 °C (-40 to 212 °F)

Operating ambient temperature range

-30 to 90 °C (-22 to 194 °F)

Hydraulic

Max. operating pressure

350 bar (5000 psi)

Flow range

5 - 150 l/min (1 - 40 gpm)

Max. internal leakage:

20 drops/min.

Switching time

Closing ≤ 100 ms
Opening ≤ 50 ms

Fluid temperature range

-20 to 80 °C (-4 to 176 °F)

Fluids:

Mineral-based or synthetics with lubricating properties at viscosities of 20 to 380 mm2/s (cSt)

Installation torque

54 - 66 Nm (40 - 49 ft-lbs)

Recommended degree of fluid contamination

Nominal value max. 10 μm (NAS 8) ISO 4406 19/17/14

MTTFD

150 years

Common cavity

CA-12A-2N

Seal kit for X=06

code RG12A2010520100
material no. R901111377

Seal kit for X=04,32

code RG12A2010530100
material no. R930003374

Seal kit coil and standard cap

code RG02Z0010000100
material no. R930067869

Seal kit coil and protective cap only for Y=B

code RG03Z0010000100
material no. R930067870

Seal kit coil and protective cap only for Y=C

code RG04Z0010000100
material no. R930069171

Electrical

Type of voltage

DC voltage

Coil type

D36

Power consumption

20 W

Note: Coils must be ordered separately
