General

Weight

0.35 kg (0.77 lbs)

Installation orientation

Unrestricted

Ambient temperature range

-30 to 90 °C (-22 to 194 °F)

Hydraulic

Max. operating pressure

350 bar (5000 psi)

Flow range

5 - 150 l/min (1 - 40 gpm)

Fatigue cycle life

1 million cycles at 350 bar

Max. internal leakage:

20 drops/min. for X= 02,06

Switching time

Closing ≤ 100 ms
Opening ≤ 50 ms

Fluid temperature range

-20 to 80 °C (-4 to 176 °F)

Fluids: Mineral-based or synthetics with lubricating properties at viscosities of 20 to 380 mm2/s (cSt)

Installation torque

130 - 150 Nm (96 - 111 ft-lbs)

Recommended degree of fluid contamination

Nominal value max. 10 μm(NAS 8) ISO 4406 19/17/14

MTTFd

150 years see RE 18350-51

Special cavity

021-E see 18325-75

Seal kit for X=02,06

code  RG21E201052010
material no.  R934003566

Seal kit for X=04,32

code  RG21E201053010
material no.  R934003567

Seal kit coil and standard cap

code RG02Z0010000100
material no. R930067869

Seal kit coil and protective cap only for Y=B

code  RG03Z0010000100
material no.  R930067870

Seal kit coil and protective cap only for Y=C

code  RG04Z0010000100
material no.  R930069171
