Weight kg (lbs)

0.13 (0.29)

Installation orientation

Optional

Ambient temperature range °C (°F)

—30 to 60 (-22 to 140)

Hydraulic

Max. operating pressure bar (psi)

350 (5000)

Rated flow l/min. (gpm)

40 (11)

Max. internal leakage drops/min.

20

Fluid temperature range °C (°F)

—20 to 80 (-4 to 176)

Fluids

Mineral-based or synthetics with lubricating properties at viscosities of 20 to 380 mm2/s (cSt)

Installation torque Nm (ft-lbs)

39-51 (29-38)

Filtration

Nominal value max. 25μm (NAS 8) ISO 4406 19/17/14

MTTFd

150 years see RE18350-51

Cavity

CA-08A-2N see RE 18325-70

Seal kit - version 05

code
material no.

RG08A2010520100
R901101437

Seal kit - version 31

code
material no.

RG08A2010530100
R901101544

Seal kit coil

code
material no.

RG12A1PNBR7010
R934003958

Other technical data

See data sheet RE 18350-50

Electrical

Type of voltage

DC voltage

Coil type

S8-356 see RE 18325-90

Supply voltage

See data sheet RE 18325-90

Nominal voltage

± 10%

Power consumption W

20

Duty cycle coil %

See performance graphs

Type of protection

See data sheet RE 18325-90
