Pressure Limits

P, A and B ports

315 bar (4500 psi)

T port: TA

120 bar (1750 psi) for AC Sol.

           TB

160 bar (2325 psi) for DC Sol.

Flow rating

See performance data

Relative duty factor

Continuous; ED = 100%

Type of protection:
ISO 4400 coils with plug fitted correctly

IEC 144 class IP65

Coil winding

Class H

Lead wires (coils type F***)

Class H

Coil encapsulation

Class F

Permissable voltage fluctuation:

Maximum

Refer to temperature limits.

Minimum

90% rated

Typical response times at 100% rated volts measured from application/removal of voltage to full spool displacement of “2C” spool at:

Flow rate P-A, B-T

40 l/min (10.6 USgpm)

Pressure

175 bar (2537 psi)

AC (~) energizing

30 ms

AC (~) de–energizing

40 ms

DC (=) energizing

120 ms n

DC (=) de–energizing

45 ms n*

Power consumption, AC
solenoids (for coils listed in model code).

Initial
VA (RMS)?

Holding
VA  (RMS) Full power coils:

Dual frequency coils at
50 Hz

700

105

Dual frequency coils at
60 HZ

105

130

Power consumption, DC solenoids at rated voltage and 20 C (68 F). Full power coils:

Others

38W

Model type “HL”

32W

Mass, Approx. kg (lb)

Single solenoid models, AC coils

4,0 (8.8)

Single solenoid models, DC coils

4,8 (10.6)

Double solenoid models, AC coils

4,5 (9.9)

Double solenoid models, DC coils

6,3 (13.9)

Temperature Limits

Minimum ambient

–20 °C (–4 °F)

Maximum  ambient:

AC 50 Hz valves

50 °C (122 °F)

AC 60 Hz valves

40 °C (104 °F)

DC valves

70 °C (158 °F)
