MAVI總線耦合器MVTBI-E4ES產品參數
Specifications | |
Incremental Encoder Characteristics | |
Incremental Connections | A+ A-, B+ B-, Z+ Z- |
Signal In/Out | Differential signal (RS422) |
Sensor Input | 5V - 24V |
Sensor Out Supply | 24V, 0.75A |
Limit frequency | 10Mhz (4-fold) |
Quadrature Decoder | 4-Fold |
Counter A, B, Z | 32 Bit Binary |
Command | Bits width in Process Image |
SSI Encoder Characteristics | |
SSI Connection | Input: D+ D- |
Signal In/Out | Differential signal (RS422) |
Sensor Input | 5V - 24V |
Sensor Out Supply | 24V, 0.75A |
Limit frequency | 62.5kbit/sec - 1Mbit/sec |
Serial Input | Adjustable 8 to 25 Bit |
Serial Input Code | Binary, Gray, BCD |
Command | Bits width in Process Image |
Isolation | 1000 V |
Power Requirements | |
E-Bus | 5V, 280 mA typ.with all inputs activated |
Field | 24V,30mA + Current sunk by each encoder |
Dimensions | |
Height | 99 mm |
Width | 45 mm |
Depth | 114,5 mm |
Mounting | On 35mm mounting rail conform to EN 50022 |
Environmental Specifications | |
Temperature | |
Operating | 0° to 65° C (32° to 149° F) |
Non operating | -40° to 85° C (-40° to 185° F) |
Humidity | 20 to 95% RH, non-condensing |
Altitude | |
Operating | Sea level to 10,000 ft. (3048m) |
Non operating | Sea level to 40,000 ft. (12192m) |
Vibration | |
Operating | 5 to 2,000 Hz.015" (.38 mm) peak-to-peak displacement 2.5g (maximum) acceleration, |
Nonoperating | 5 to 2,000 Hz.030" (.76 mm) peak-to-peak displacement 5.0 g (maximum) acceleration, |
Shock | |
Operating | 30 g peak acceleration 11 msec duration |
Nonoperating | 50 g peak acceleration 11 msec duration |
MAVI總線耦合器MVTBI-E4ES產品介紹
mvTBI-E4ES是功能強大的4通道增量式編碼器/ SSI /兩個脈沖編碼器EtherCAT端子。
對于差分編碼器和雙脈沖編碼器，mvTBI-E4ES均提供差分輸入（RS422）和32位計數器正交解碼器，最大頻率為10 MHz。 每個計數器步長都覆蓋輸入信號的上升沿和下降沿。
可以測量以下一個或多個參數：位置，頻率/周期，時間和速率。
對于頻率/周期測量，可以具有外部或內部基準時序。
對于SSI編碼器，mvTBI-E4ES終端提供差分輸入（RS422），最大采集速度為1Mbit / sec。 是否可以僅獲取頭寸或頭寸和時間。
mvTBI-E4ES的每個通道都可以通過軟件以任何支持的模式分別配置。
MAVI總線耦合器MVTBI-E4ES其他常見型號：
MAVI mvTBI-E4ES
MAVI mvTBI-EBC
MAVI mvTBI-E8AI
MAVI mvTBI-E4AO
MAVI mvTBI-E8DIO
MAVI mvTBI-E4ES
MAVI mvTBI-EPWE
