SEALITE燈SLC310 compact技術參數
SL-C310 | Compact |
Light Characteristics | |
Light Source | LED |
Available Colours | Red, Green, White, Yellow, Blue |
Typical Maximum Intensity | Red - 121, Green - 88, White - 156, Yellow - 95 |
Visible Range (NM) | AT @ 0.74: 3–5 |
Horizontal Output (degrees) | 360 |
Vertical Divergence (degrees) | >7 |
Available Flash Characteristics | Up to 310 IALA recommended (user adjustable) |
Intensity Adjustments | Multiple intensity settings |
LED Life Expectancy (hours) | >100,000 |
Electrical Characteristics | |
Current Draw (mA) | Refer to Sealite Solar Calculator |
Circuit Protection | Integrated |
Nominal Voltage (M) | 12 |
Autonomy (nights) | >60 (14 hour darkness, 12.5% duty cycle) |
Solar Characteristics | |
Solar Module Type | Monocrystalline |
Output (watts) | 20 (4 x 5watt) |
Charging Regulation | MPPT |
Power Supply | |
Battery Type | SLA (Sealed Lead Acid) |
Battery Capacity (Ah) | 12 |
Physical Characteristics | |
Body Material | Aluminium chassis with UV-stabilised rubber corners & gaskets. Polymer composite-moulded top and base |
Lens Material | LEXAN? Polycarbonate – UV stabilised |
Lens Diameter (mm/inches) | 99 / 3 7/8 |
Lens Design | Single LED Optic |
Mounting | 3 and 4 hole 200mm bolt pattern |
Height - Base Model (mm/inches) | 484 / 19 1/16 |
Height - SATCOM Model (mm/inches) | 504 / 19 27/32 |
Width (mm/inches) | 234 / 9 1/4 |
Mass (kg/lbs) | 9.1 / 20 |
Service Life | 15 years ^ |
Environmental Standards | |
Shock | MIL-STD-202G Test Condition H, Method 213B 30G vertical and 35G horizontal shock |
Vibration | MIL-STD-202G, Test Condition B, Method 204D 5G in all axes |
Ice Loading | Rated to withstand 22kg/m2 |
Salt Fog | MIL-STD-810F Method 509.4 |
Rain Test | MIL-STD-810F Method 506.4 procedure 1 |
Wind Exposure | Rated to withstand 140 knots |
Humidity | MIL-STD-810F method 507.4 (0 – 100%, condensing) |
Temperature Range | -30 to 50°C |
Compliance | |
CE | EN61000-6-2:2005, IEC61000-4-2:2008, IEC61000-4-3:2010, IEC61000-6-1:2016 |
IALA | Signal colors compliant to IALAE-200-1 |
Ingress Protection | IP68 |
