DANFOSS變頻器FC-302P18KT5E20H1XGCXXXSXXXXA0B2CXXXXD0 131H4765技術參數
Product details | |
Gross weight | 20 kg |
Net weight | 19.04 kg |
Volume | 144.67 l |
EAN | 5702427551114 |
VLT? AUTOMATIONDRIVE FC 300 SERIES | |
Product View (Switch) GLBL | Global (Standard) |
Product Group FC- | VLT? AutomationDrive FC- |
Series 302 | 302 |
Power Rating P18K | (P18K) 18.5 KW / 25 HP |
Phase T | Three phase |
Mains Voltage 5 | 380 - 500 VAC |
Enclosure E20 | (E20) IP20 / Chassis |
RFI Filter H1 | (H1) RFI Class A1/B (C1) |
Brake - Safe Stop X | No brake chopper |
LCP G | Graphical Loc. Cont. Panel |
Coating PCB C | Coated PCB |
Mains Option X | No Mains Option |
Adaptation A X | Standard Cable Entries |
Adaptation B X | No adaptation |
Software Release SXXX | Latest release std. SW. |
Software Language Pack X | Standard Language Pack |
A Option A0 | PROFIBUS DP MCA 101 |
B Option B2 | MCB-112 PTC Therm. Card |
C0 Option MCO CX | No C0 option |
C1 Option X | No C1 option |
C Option Software XX | No software option |
D Option D0 | MCB-107 24V DC backup |
Frame Size B4 | B4 |
Typecode Part 1 | FC-302P18KT5E20H1XGC |
Typecode Part 2 | XXXSXXXXA0B2CXXXXD0 |
Product Catalog NO_VIEW | NO VIEW |
Power 160% (HO) [KW] | 18.5 |
Power 110% (NO) [KW] | 22 |
Height [mm] | 516,0 |
Width w/ no C options [mm] | 229,0 |
Depth [mm] | 242,0 |
Depth with Option A/B [mm] | 242,0 |
kVA | 26 |
Power Loss NO [W] | 525 |
Power Loss NO [W] | 525 |
Power Loss HO [W] | 444 |
Power Loss HO [W] | 444 |
Continuous Current (NO) [A] | 44 |
Intermittent Current (NO) [A] | 48.4 |
Continuous Current (NO) [A] | 40 |
Intermittent Current (NO) [A] | 44 |
Continuous Current (HO) [A] | 37.5 |
Intermittent Current (HO) [A] | 60 |
Continuous Current (HO) [A] | 34 |
Intermittent Current (HO) [A] | 54.4 |
ATEX Marking 1 | ATEX: II (2) G [Ex eb Gb] [Ex |
ATEX Marking 2 | db Gb] / II (2) D [Ex tb Db] |
DANFOSS變頻器FC-302P18KT5E20H1XGCXXXSXXXXA0B2CXXXXD0 131H4765介紹
VLT? AutomationDrive FC-302
(P18K) 18.5 KW / 25 HP，三相
380 - 500 VAC，(E20) IP20 / 底盤
(H1) RFI 等級 A1/B (C1)
無制動斬波器
圖形化本地控制板
涂層 PCB，無電源選項
最新發布標準軟件
框架：B4
無 C1 選項，MCB-107 24V DC 備用電源
PROFIBUS DP MCA 101，MCB-112 PTC 熱敏卡
ATEX：II (2) G [Ex eb Gb] [Exdb Gb] / II (2) D [Ex tb Db]
VLT? AutomationDrive FC-302
(P18K) 18.5 KW / 25 HP, Three phase
380 - 500 VAC, (E20) IP20 / Chassis
(H1) RFI Class A1/B (C1)
No brake chopper
Graphical Loc. Cont. Panel
Coated PCB, No Mains Option
Latest release std. SW.
Frame: B4
No C1 option, MCB-107 24V DC backup
PROFIBUS DP MCA 101, MCB-112 PTC Therm. Card
ATEX: II (2) G [Ex eb Gb] [Exdb Gb] / II (2) D [Ex tb Db]
DANFOSS變頻器FC-302系列其他常用型號：
DANFOSS FC-302P4K0T5E20H1XXXXXXSXXXXAXBXCXXXXDX 131B0001
DANFOSS FC-302P5K5T5E20H1XXXXXXSXXXXAXBXCXXXXDX 131B0002
DANFOSS FC-302P7K5T5E20H1XXXXXXSXXXXAXBXCXXXXDX 131B0003
DANFOSS FC-302P7K5T5E20H1BXXXXXSXXXXAXBXCXXXXDX 131B0004
DANFOSS FC-302P5K5T5E20H1BXXXXXSXXXXAXBXCXXXXDX 131B0005
DANFOSS FC-302P4K0T5E20H1BXXXXXSXXXXAXBXCXXXXDX 131B0006
DANFOSS FC-302P2K2T2E20H1XXXXXXSXXXXAXBXCXXXXDX 131B0007
DANFOSS FC-302P2K2T2E20H1BXXXXXSXXXXAXBXCXXXXDX 131B0008
DANFOSS FC-302P3K7T2E20H1XXXXXXSXXXXAXBXCXXXXDX 131B0009
DANFOSS FC-302P3K7T2E20H1BXXXXXSXXXXAXBXCXXXXDX 131B0011
DANFOSS FC-302P18KT5E20H1XGCXXXSXXXXA0B2CXXXXD0 131H4765
