Mechanical and environment withstand characteristics

Housing

ABS, grey - IP65

Weight

1.1 kg (approx.)

Dimensions

200x120x75 mm (without antenna and cable glands)

Operating temperature range

-20°C to +50°C

Storage temperature range

-30°C to +70°C

Cable lead-outs

Power supply or IR module

1 M16 cover (cable diameter ? 5 to 7 mm) (1)

Control outputs

1 M25 plastic cable gland (cable diameter ? 14 to 20 mm)

Radio characteristics (complying with ETS 300 220)

Frequency

64 programmable frequencies in 433-434MHz (see list on page 6)

Antenna

? wave fixed antenna (can be unplugged as an accessory with kit ref :OWR01)

Sensitivity

< -100dBm

Electrical characteristics

Power supply and consumption

(with 2 safety relays, the "Horn" relay and 6 function relays pulled in)

DC version

12VDC, -5% to +30%, 550 mA
24VDC, -20% to +20%, 430 mA

AC version n°1

24VAC, -15% to +10%, 1 A
48VAC, -15% to +10%, 475 mA

AC version n°2

115VAC, -15% to +10%, 200 mA
230VAC, -15% to +10%, 90 mA

Control

1 "Horn" relay + 6 function relays

Safety

2 relays with linked and guided contacts

Outputs

Independent 1 NO contact relay

Category

DC13 0,5A / 24VDC AC15 2A / 230VAC

Max. breaking capacity 2000VA

Max. current 8A (control relay), 6A (safety relay) Min. current 10 mA (12 Vmin.)

Max. voltage 250VAC

Service life with 230VAC, 70VA, cosphi=0,75 : Control relay : 3x106 cycles

Safety relay : 4,5x106 cycles

Response time

On start-up : 0,5 s max.

On control : 0,07 s max.

Active shutdown time

0,16 s max.

Passive shutdown time

1,15 s max.

Indicator lights

1 green indicator light : power supply

1 red + 1 green diagnostic indicator lights

1 red status indicator light per relay

Power supply protection

Against polarity inversions for DC versions

Against overcurrent by fuse

Mechanical and environment withstand characteristics

Housing

ABS, yellow - IP65 - Mechanical button protection

Weight (with battery)

240 g

Dimensions

46 x 78 x 143 mm

Operating temperature range

-20°C to +50°C

Storage temperature range

-20°C to +50°C

Fast charging temperature

0°C to +40°C

Fast charging complete time

2 hours 30 minutes

Electrical and radio characteristics

Power supply

Lithium battery

Endurance (buttons typical average use at +20°C)

50 hours / 50 % Transmit time

Frequency

64 programmable frequencies in 433-434MHz (see list below)

Transmit power

<10 mW (license not required) built-in antenna

Modulation

FM

Average range (1)

230m in typical industrial environment 600m in unobstructed area
