Detector type

Indium Antimonide (InSb)

Spectral response

<1.0 μm to 5.3 μm

Resolution (pixels)

640 x 512

1024 x 1024

1280 x 1024

Pixel pitch

20 μm

12 μm

25 μm

12 μm

IMAGING ELECTRONICS

Image Data Stamp

Optional IRIG, GPS with on-board receiver

Frame rate @ max window size

119 Hz

475 Hz

76 Hz

119 Hz

Integration time

<150 ns to full frame

Dynamic range

14-bit with 13-bit option to increase frame rate at small window sizes

Windowing

User defined in 4 x 1 increments; min width = 320, min height = 32

Integration type

Snapshot, automatic selection of integrate while read or integrate then read

Ultra low latency sync

Sync I/O, integration out

Image data

Simultaneous CameraLink, GigE & HDMI

Communications

Serial over Camera Link & GigE

Software control

Cross platform GenICam compliant

PERFORMANCE

Non uniformity correction

up to 12 on board tables

NEdT

18 mK

30 mK

18 mK

30 mK

Well capacity (electrons)

7 M

2 M

10 M

2 M

Operability

99.80%

99.60%

99.60%

99.60%

OPTICS

Camera f/#

f/2.3, & f/4.0 standard; custom cold shields available on request

Cold filter

3.0 μm - 5.0 μm or no cold filter standard, SWIR, CO2 or custom filters on request

Lens mount

Bayonet

Bayonet

Bolt hole pattern

Bayonet

Optional filter wheel

Motorized four position cold filter wheel; 25.4 mm diameter x 1.0 mm thick filters

GENERAL

Power @ 24 VDC

20 W

25 W

35 W

28 W

System weight

<7 pounds

<7 pounds

<10 pounds

<7 pounds

Size

5.1” x 5.8” x 8”

5.1” x 5.8” x 8”

6” x 6” x 9”

5.1” x 5.8” x 8”

Operating temperature range

-40° C to +55° C (-40° F to +131° F)

Storage temperature range

-55° C to +80° C (-67° F to +176° F)

Environmental rating

IP-51

Mounting holes

2x 1/4-20 & 4x #10-24
