Absolute position values

EnDat 01

Positions/U

8,192 (13bit)

Distinguishable within ... revolutions

4,096

Code

Dual

Electr. llwed speed 1 with system accuracy

1,500 min-1 1±1 LSB
12,000 min-1 1 ±50 LSB

Incremental signals

1 Vss

Increments

2048

Typical limit frequency.3 dB

≥400 kHz

Power supply

3.6...14V

Max. current consumption

≤ 200 mA

Electrical connection

Flange socket

Max, cable length

75 m

Drive shaft

ne side open hollow shaft D = 12 mm

Mech. permitted speed

max. 10,000 min-1

Starting torque

≤ 0.01 Nm

Moment of inertia of rotor

4.3x 10-6 kgm2

Permitted axial moving of the drive shaft

±1mm

Vibration 55 bis 2,000 Hz

≤ 300 m/s2 (EN60068-2-6)

Shock 6ms

≤ 1,000 m/s? (EN60068-2-27)

Operating temperature

-40 ...100 ℃

Protection class EN 60529

IP 67 on the housing; IP 64 on the shaft input

Mass

approx. 0.30 kg
