DATA

Operating range

10-57 V DC

Nominal current consumption1 (max)

80 mA

Sound pressure level

105 dB(A)

Sound pressure level @DIN-tone

104 dB(A)

Sound level reduction

max. –12 dB via potentiometer

Alarm tones

80 thereof 4 tones are externally selectable

Operating temperature

–40 °C ... +55 °C

Storage temperature

–40 °C ... +70 °C

Relative humidity

90%

Protection system according to EN 6052

IP 66 (EN 60529), NEMA Type 4 & 4x

Protection class

II

Duty cycle

100%

Material

PC / ABS blend similar to RAL 3000 (flame red) | RAL 7035 (light grey) | RAL 9003 (signal white)

Cable entry

3x M20 knock-outs on side, 1 knock-out on back

Integrated seal with cable entry

7-13 mm (Feed-through grommet)

Connecting terminals

0.14 - 2.5mm簡 fine stranded / AWG24 - AWG 14

Weight

270 g
