Housing

Plug-in COMBICOM screw terminals for max. 2.5 mm2
IP20
Installation on 35-mm top hat rail in accordance with DIN 46277

Dimensions

117 × 50 x 117 mm

Power supply

24 VDC +10/-15%

Power consumption

Max. 9 W

Display

1.77” TFT LCD, 30 x 37 mm

Control outputs

Quantity: 3, optocoupler isolated, passive, max. 30 VDC, max. 30 mA
Function: limits, status, weight, etc.

Control inputs

Quantity: 3, optocoupler isolated, max. 30 VDC, max. 10 mA
Function: zero, tare, etc.

Load cell connection

All strain gauge load cells; 6 or 4-wire connection is possible

Load cell supply

5 VDC (±2,5 VDC), short-circuit-proof

Load impedance

Min. 75 Ω, e.g. 4 load cells each with 350 Ω

Measuring principle

Measuring amplifier: Delta-Sigma converter
Measurement time: min. 10 ms - max. 640 ms

Sensitivity

Smallest usable measurement signal 0.5 μV/d

Input signal

0 to 20 mV (for 100% maximum capacity)

Linearity

< 0.01%

Temperature effect

Zero point Tk0m <0.01% /10K @ 1mV/V
Measuring range TKspan <±4 ppm/K

Digital filter for load cell connection

4th order (low pass), Bessel, aperiodic or Butterworth

Ethernet interface

TCP/IP web service for configuration
ModBus TCP
IP address via DHCP or fixed input

Field bus

/01 and /11: Profibus-DP-V0, 9-pin D-Sub female
/04: DeviceNet, 5-pin terminal
/05: CC Link, 5-pin terminal
/06: ProfiNet, RJ45
/07: Ethernet IP, RJ45
/08: EtherCAT, RJ45

Analogue output

0/4 … 20 mA
Resolution of 20,000 divisions at 20 mA
Load impedance 500 Ω max.
Function freely configurable

Serial interface

RS 485
Protocol:
Remote displays for PR 5110,
ModBus-RTU and
SMA

Ambient temperature range

Operation: -10 … +55°C (Power-on range from 0 °C)
Storage: -40 … +70°C

Packaging dimensions

210 × 140 x 65 mm

Weight

Net: 0.30 kg

Certificates

EN 61326, CE, ROHS, REACH
