Supply voltage

11-27 V DC, twisted in pairs and shielded

Current load

< 200 mA at 11 V DC, < 110 mA at 27 V DC (unloaded)

Total resolution

≤ 24 bit (optional 25 bit)

Number of steps / revolution

≤ 8.192

Measurement range

Standard

≤ 4.096 revolutions (12 bit)

Expanded

≤ 256.000 revolutions

Baud rate (adjustable)

125 kbit/s, line length up to 500 m
250 kbit/s, line length up to 250 m
500 kbit/s, line length up to 100 m

Station addresses

0 – 63, adjustable via DIP switches

Transmission

twisted in pairs and shielded copper cable

CAN DeviceNetTM interface

CAN field bus interface (opto ... -isolated)

Data transmission

CAN bus driver (ISO/DIS 11898)

Terminating resistor

121 ohm, selectable via DIP switches

Special features

Programming of the following parameters via the
CAN-BUS:
- Direction of rotation
- Output code (binary, gray)
- Measuring length in steps
- Measuring length in revolutions
- Adjustment
- 7 special outputs
