Power supply and consumption

12÷24 VDC ±10%; 5 W

Number of load cells ? Load cells supply

up to 16 (350 Ω) - 4/6 wires ? 5 VDC/240 mA

Linearity ? Analog output linearity (only for TLM8)

<0.01% full scale ? <0.01% full scale

Thermal drift ? Analog output thermal drift (only for TLM8)

<0.0005% full scale/°C ? <0.003% full scale/°C

A/D Converter

8 channels - 24 bit (16000000 points) - 4.8 kHz

Divisions (with measurement range ±10 mV and sensitivity 2 mV/V)

±999999 ? 0.01 μV/d

Measurement range

土39 mV

Usable load cells sensitivity

+7 mVN

Conversions per second

600/s

Display range

±999999

Decimals●Display increments

0+4●x1x2x5x10x20x50x100

Digital filter●Readings per second

21 levels ●5+ 600 Hz

Relay outputs

5- max 115 VAC/150 mA

Optoisolated digital inputs

3- 5+24 VDC PNP

Serial ports

RS485

Baud rate

2400, 4800, 9600, 19200, 38400, 115200 (bit/s)

Analog output (only for TLM8)

16 bit = 65535 divisions. 0+ 20 mA; 4+20 mA (up to 400 Q)
0+10 V; 0+5 V (min 2 kQ)

Humidity (condensate free)

0.85

Storage temperature

-30 °C +80 C

Working temperature

-20 °C +60 C
