General

Ambient   temperature:

0 to +50 °C

Storage   temperature:

-20 to +70 °C

Dimensions:

22,5 x 91,5 x 90 mm (WxDxH)

Mounting:

TS 35 rail

Protective system:

IP 20

Supported   Measurement-Systems:

Singleturn-, multiturn- and linear encoders

SSI-Encoders   (SK20.2)

Signal level:

RS422

Code:

Gray-/binary-code

Clock frequency:

230 KHz (stand alone)

70-600 KHz (parallel connection)

Encoders with   Start/Stop-Signal (SK20.4)

Interface:

Digital P-interface/R-module

Resolution:

25 / 50 mm

Ready / fault   signal

Transistor output:

max. 50 mA

Supply voltages

Nominal:

24 VDC

Permissible range:

18 - 30 VDC

Input current:

ca. 0,1 A

Reverse polarity   protected by diod

Analog output   (current or voltage)

Resolution:

16 bit

Cycle time:

1 ms

Current output

 - Signal level:

4 - 20 / 0 - 20 mA

 - Max. error:

0,1%

 - Load impedance:

￡ 600 W

Voltage output

 - Signal level:

0 - 10 V

 - Max. Error:

0,2%

 - Output impedance:

0 W

 - Load impedance:

3 1 KW
