Model:

PEY-155C

Power supply voltage:

DC12-24V (maximum operating range DC10-30V, including ripple 10%)

Current consumption:

Light emitter: 20mA or less, Light receiver: 15mA or less

Detection object:

Opaque object with ? 12mm or more

Detection distance:

15m or less, Light emitter axis deviation ±2.5° or less

Light source:

Red LED

Spot diameter:

? 1.1m (at 15m)

Response time:

0.5ms or less

Operation mode:

Light on (operates when light is received)/Dark on (operates when light is blocked)
Volume switching (factory default: operates when light is blocked)

Control output:

NPN open collector
Allowable load voltage/current DC30V/100mA or less, residual voltage 1.8V/100mA or less

Protection circuit:

Reverse connection protection, overcurrent protection (control output)

Sensitivity adjuster:

Factory default: Maximum sensitivity

Indicator:

Stability indicator: Green LED (no floodlight)
Output indicator: Orange LED (no floodlight)

Connection:

Extractable cable ? 3.8mm 2m long
Floodlight: 0.2mm2 (AWG24) 2-core
Receiver: 0.2mm2 (AWG24) 3-core

Protection:

IP67

Material:

Case: ABS (black) with glass fiber
Lens (front cover): PMMA (red)

Weight:

Floodlight: Approx. 50g
Receiver: Approx. 55g

External dimensions:

W11 × D20 × H31mm

Accessories:

Mounting bracket set (2 brackets, 4 M3 mounting screws)

Ambient illumination:

Sunlight: 10,000 lx or less
Incandescent lamp: 3,000 lx or less

Ambient temperature:

-25 to +55℃ (storage: -40 to +70℃) but do not freeze

Ambient humidity during use:

35 to 85% RH (storage: 35 to 95% RH) but do not condense

Vibration resistance:

1.5mm double amplitude, 10 to 55Hz, 2 hours each in X, Y, and Z directions

Shock resistance:

1000m/s2, 3 times each in X, Y, and Z directions

Insulation resistance:

20MΩ or more (DC500V megger)

Noise resistance:

EN61000-4-2:2009
  Contact: level 2 (±4kV)
  Air: level 3 (±8kV)
EN61000-4-3:2006+A1:2008+A2:2010
  80-1000MHz, level 3 (10V/m)
  1.4-2.0GHz, level 2 (3V/m)
  2.0-2.7GHz, level 1　(1V/m)
EN61000-4-4:2004+A1:2010
  DC power ports: level 3　(±2kV)
  signal ports: level 4　(±2kV)
EN61000-4-6:2009
  DC power ports: level 3　(10V)
  signal ports: level 3　(10V)
EN61000-4-8:2010
  level 4 (30A/m), continupus field
