Contact Type

Contact maker normally open (MOSFET)

Max. Switching Capacity (Relay Output)

DC 15 A

Operating Temperature

-22 °F to +104 °F (-30 °C to +40 °C)

Agency Approvals

VDE,EAC

Technical Data

Voltage

DC 20 to 56 V

Service LIfe

> 100,000 cycles

Operating/Storage Humidity

Max. 90 % RH (non-condensing)

Control Contact

3 mA at DC 20 V / 4.5 mA at DC 24 V
14 mA at DC 48 V / 17 mA at DC 56 V

Connection1

6-pole terminal: stranded wire AWG 16 (1.5 mm2);
max. AWG 12 (2.5 mm2)

Housing

Plastic, UL 94V-0, grey (bicolor)

Mounting

Clip for 35 mm DIN rail, EN 60715

Mounting Position

Vertical

Storage Temperature

-40 to +176 °F (-40 to +80 °C)

Dimensions

3.7 x 2.1 x 1.7" (93 x 53 x 44 mm)

Weight

Approx. 2.3 oz (65 g)

Protection Type

IP20
