Operating principle

Diffuse reflection principle

Operating range

Guaranteed operating range

Operating range, white 90%

0.001 ... 0.7 m

Operating range, gray 50%

0.001 ... 0.59 m

Operating range, gray 18%

0.003 ... 0.39 m

Operating range, black 6%

0.005 ... 0.28 m

Operating range limit, white 90%

0 ... 1 m

Operating range limit, gray 50%

0.001 ... 0.85 m

Operating range limit, gray 18%

0.003 ... 0.55 m

Operating range limit, black 6%

0.002 ... 0.4 m

Operating range limit

Typical operating range

Light source

LED, Red

Wavelength

620 nm

Transmitted-signal shape

Pulsed

LED group

Exempt group (in acc. with EN   62471)

Protective circuit

Polarity reversal protection
  Short circuit protected

Supply voltage UB

10 ... 30 V, DC, Incl. residual   ripple

Residual ripple

0 ... 15 %, From UB

Open-circuit current

0 ... 20 mA

Number of digital switching   outputs

2 Piece(s)

Type

Digital switching output

Switching element

Transistor, PNP

Switching principle

Light switching

Switching element

Transistor, PNP

Switching principle

Dark switching

Switching frequency

500 Hz

Response time

1 ms

Readiness delay

300 ms

Number of connections

1 Piece(s)

Function

Signal OUT
  Voltage supply

Type of connection

Cable

Cable length

2,000 mm

Sheathing material

PUR

Cable color

Black

Number of conductors

4 -wire

Wire cross section

0.2 mm2

Dimension (W x H x L)

14 mm x 32.5 mm x 20.2 mm

Housing material

Plastic

Plastic housing

ABS

Lens cover material

Plastic

Net weight

70 g

Housing color

Black
  Red

Type of display

LED

Number of LEDs

2 Piece(s)

Operational controls

Teach button

Ambient temperature, operation

-40 ... 60 °C

Ambient temperature, storage

-40 ... 70 °C

Degree of protection

IP 67

Protection class

III

Approvals

c UL US

Standards applied

IEC 60947-5-2
