Controllo

a microprocessore

Auxiliary supply voltage

100÷440Vac

Frequency

50Hz/60Hz

Voltage measuring input

100÷600V (-15% / +10%)

Current measuring input

5A (1A programmable)

Current reading range

from 25mA to 6A (from 10mA to 1.2A)

Automatic current way sensing

yes

Operation in systems with cogeneration

yes

Power consumption

12VA (10.5W)

Output relay

5A - 250Vac

Cosφ adjustment

from 0.5 ind. to 0.5 cap.(tan φ da -1.732 a +1.732)

Step switching time

1s ÷ 1000s (20ms with STR4NO module)

Alarm relay

yes

Degree of protection

IP55 on front, IP20 at terminals

Operating temperature

from -30°C to +70°C

Storage temperature

from -30°C to + 80°C

Front optical port

for communication USB or WIFI with dedicated accessories

Temperature control

from -30°C to +85°C

Compliance with the standards

IEC 61010-1; IEC 61000-6-2; IEC 61000-6-3; UL508; CSA C22-2 nr.14

Output relay number

8 (expandable up to 16)

Dimensions

144x144mm

Weight

0.98kg

Part number

6CF46411000
