design

cuboidal

operating mode

proximity   switch/reflective mode
  reflective barrier
  window mode

particularities

kleine   quaderf?rmige Bauform
  schlankes Schallfeld
  UL Listed

ultrasonic-specific

means of   measurement

echo propagation   time measurement

transducer   frequency

380 kHz

blind zone

20 mm

operating range

150 mm

maximum range

250 mm

resolution

0.20 mm

reproducibility

± 0.15 %

accuracy

temperature drift   0.17 %/K

electrical data

operating voltage   UB

20 - 30 V d.c.,   reverse polarity protection

voltage ripple

± 10 %

no-load current   consumption

≤ 25 mA

type of connection

4-pin M8 initiator   plug

outputs

output

switching output
  pnp: Imax = 200 mA (UB-2V)
  NOC/NCC adjustable, short-circuit-proof

switching   hysteresis

2.0 mm

switching frequency

25 Hz

response time

24 ms

delay prior to   availability

< 300 ms

inputs

description

external   synchronisation from rectangular signal with a defined pulse width

input 1

synchronisation   input

housing

material

ABS

ultrasonic   transducer

polyurethane foam,   epoxy resin with glass contents

class of protection   to EN 60529

IP 67

operating   temperature

-25°C to +70°C

storage temperature

-40°C to +85°C

weight

10 g

further versions

cable connection   (on request)

technical   features/characteristics

temperature   compensation

no

controls

1 push-button

scope for settings

Teach-in via   push-button

Synchronisation

Twin mode or   external synchronisation

multiplex

no

indicators

1 x LED green:   working, 1 x LED yellow: switch status

particularities

kleine   quaderf?rmige Bauform
  schlankes Schallfeld
  UL Listed
