Optical data

Measurement range 1)

20 … 500mm

Resolution 2)

0.1 … 0.5mm

Hysteresis 2)

0.6 … 32mm

Light source

laser

Laser class

2 acc. to IEC 60825-1:2007

Wavelength

650 nm (visible red light)

Max. output power

<1.2 mW

Pulse duration

4ms

Light spot

2x6 mm2 at 500mm

Error limits (relative to measurement distance)

Absolute measurement accuracy

± 2% up to 200mm / ± 4% 200 … 500mm

Repeatability

± 1% up to 200mm / ± 3% 200 … 500mm

B/W detection thresh. (6 … 90% rem.)

＜1.5%

Temperature drift

＜=0.2%/°C

Timing

Measurement time

2 … 7ms

Response time

＜= 20ms

Delay before start-up

＜= 300ms

Electrical data

Operating voltage UB

10 … 30V DC (incl. residual ripple)

Residual ripple

＜= 15% of UB

Open-circuit current

＜= 50mA

Switching output/function 4)

2 push-pull switching outputs

pin 2: Q2, PNP light switching, NPN dark switching pin 4: Q1, PNP light switching, NPN dark switching

Signal voltage high/low

＞=(UB -2 V)/≤2V

Indicators

Green LED  continuous light

ready

flashing (no teach)

fault, teach values were not applied

off

no voltage

Yellow LED continuous light

object within teach-in measurement distance (output Q1)

flashing (no teach)

teach values were not applied

off

object outside teach-in measurement distance (output Q1)

Mechanical data

Housing

metal

Optics cover

glass

Weight

70g

Connection type

M12 connector, 5-pin, turning

Environmental data

Ambient temp. (operation/storage)

-40°C … +50°C/-40°C … +70 °C

Protective circuit 6)

2, 3

VDE safety class 7)

II,  all-insulated

Protection class 8)

IP 67, IP 69K 9)

Environmentally tested acc. to

ECOLAB

Standards applied

IEC 60947-5-2
