Grating Period

20μm

Signal Period

20μm

System Resolution

5μm - 1.2nm; determined by customer electronics

Linear accuracy*

Laser Tape Scale

Glass Scales

Short-travel  Accuracy

Determined by correction of gain mismatch, offset and phase in the customer electronics

Long-travel Accuracy

± 5μm/m after two-point linearization in the customer's controller

High accuracy grade: ≤ ±1μm for scales up to 130mm ≤ ±2μm for scales from 130mm to 1m
Standard accuracy grade: ≤ ±1.5μm for scales up to 130mm ≤ ±5μm for scales from 130mm to 1m

Sensor Size

W: 13.49mm

0.531"

L: 32.00mm

1.260"

H: 8.73mm

0.344"

Operating and Electrical Specifications

Power Supply:

5VDC ±5% @ 48mA when used with
recommended termination (see installation manual)

Temperature

Operating:

0 to 70°C

Storage:

-20 to 85°C

Humidity:

10 to 90% RH non-condensing

EMI：

CE Compliant

Shock:

300G 0.5 ms half sine

Vibration:

30G at 17Hz

Sensor Weight:

6g (Sensor without cable)

Sensor Cable:

Double Shield
Maximum length: 20m (contact MicroE Systems for
applications >5m)
Diameter: 3.6mm (0.142”)
Flex Life: 20 x 106
cycles @ 20mm bending radius
