Model Specific

Adjustment Type:

Potentiometer

Connection Type:

Cabled, 6ft

Housing Type:

18MM

Output Transistors:

NPN: Sink up to 100mA
All outputs are continuously short circuit protected

Supply Voltage:

10 to 30 VDC
Polarity Protected

LED Light Source

Infrared = 880nm

Sensing Range:

6in

Family Specific

Current Requirements:

30mA (exclusive of load)

Remote AUTOSET Input:

Opto-isolated momentary sinking input (10 milliamps)

Response Time

Light State response = 600μs (1,100μs, Thru-Beam)
Dark State response = 600μs (1,100μs, Thru-Beam)

Light/Dark "ON" Operation:

Light “ON” achieved by connecting white wire to negative lead
Dark “ON” achieved by connecting white wire to positive lead

Range:

Dependent on model, see Selection Guidelines Note: 5 VDC models, range reduced by 10%

Hysteresis:

Approximately 20% of signal

Light Immunity:

Responds to sensor’s pulse modulated light source, resulting in high immunity to most ambient light, including high intensity strobes

Diagnostic Indicators:

Red LED = Output Status
Green LED = Power “ON”

Ambient Temperature:

-40°C to 70°C (-40°F to 158°F)

Rugged Construction:

Chemical resistant, high-impact polycarbonate housing
Waterproof ratings: NEMA 4X, IP66
