DEPA氣動隔膜泵DH50-S1-ZTZ規格描述
DH50-S1-ZTZ |
DEPA compressed air diaphragm pump |
Series: L flanged version |
Prod.ber. Housing parts: stainless steel 1.4404, el.pol. |
Prod.ber. Membrane plate: without |
Control block: aluminum, nickel-plated |
Membrane: PTFE DEPA E4, FDA, conductive. |
Valve seats: PTFE |
Valve balls: PTFE/steel core |
Suction connection: Tri Clamp DIN 32676-B ISO |
Pressure connection: Tri Clamp DIN 32676-B ISO |
Control valve: internal |
Compressed air connection: internal thread. ISO 228-G3/4 |
Silencer: PE |
Surface: electropolished/nickel plated |
Explosion protection / ATEX: II 2GD Ex h IIB T6.. .T4 GbDb |
DEPA氣動隔膜泵DH系列其他常用型號：
DEPA DH50-S1-ZTZ
DEPA DH15-FA-SET
DEPA DH25-FA-SET
DEPA DH40-FA-SET
DEPA DH50-FA-SET
DEPA DH80-FA-SET
DEPA air operated diaphragm pump NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業集產品開發、設計、制造、銷售于一體，代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于DEPA氣動隔膜泵DH50-S1-ZTZ的疑問，請隨時致電我們，愛澤工業（86-021-31006702）。我們將盡全力解決您的問題。
If you have any question for DEPA products, please feel free to dial 0086-21-3100 6702/ send request email to [email protected] / browse our website: www.www.jguvm.cn.
