DISPL ACEMENT:

080 - 80 [cm/rev] maximum, Frame size3

VARIATION:

1 - Standard

PORTS / THREADS:

1 - BSPP ports; Metric Threads

SEALS:

N- NBR seals / FKM shaftseal

COMPENSATOR PART1:

S- 30kW@1500rpm-setting for PV032 to PV180

COMPENSATOR PART3: .

C- Standard with integrated pmax. Pilot

Body Material:

Cast Iron

Displacement:

16 to 360 cm3/rev, 1 to 22 inch3/rev

Flow Rate:

12 to 166 Gal/min, 48 to 630 L/min

Technology:

Hydraulics

Maximum Operating Speed:

3000 RPM

Maximum Fluid Temperature:

115°C, 239 °F

Shaft Type:

SAE, ISO

Port Type: .

Flange, Straight Threaded

Direction of Rotation:

Clockwise, Counter Clockwise

Sensor Type:

Pressure, Displacement

Drain Option:

Yes

Radial Load Capacity:

Consult Parker

Maximum Kinematic Viscosity:

3880 SUS

Energy Recovery Capability:

No

Charge Pump Included:

No

ROTATION:

R- Clockwise

MOUNTING INTERFACE / SHAFT:

K- metric 4bolt-mount; metric keyed shaft

THRUDRIVE PAD AND COUPLING:

T1 - Single pump prepared for thru drive,no coupling

CONTROLS GROUP:

Hydromechanical controls with torquelimiter override

COMPENSATOR PART2:

L- Horsepower with pressure compensator

Pump Type:

Piston, Variable

Configuration:

Single, Tandem, Multiple

Operating Pressure:

420 bar, 6000 psi

For Fluid Type:

Standard Hydraulic Fluid, Water Glycol, Biodegradable, Fire Resistent

Media:

Hydraulic, Liquid

Minimum Fluid Temperature:

-40。C, -40 °F

Weight:

186 kg, 410 lb

Mounting Option:

SAE, ISO

Port Connection:

SAE, ISO, BSPP

Circuit Path:

Open

Maximum Noise Level:

96 dBA

Filter Included:

No

Minimum Kinematic Viscosity:

80 SUS .

Thru-Drive Capability:

Yes

Control Method:

Pressure, Remote Pressure, Load Sense,Electronic Control, Unloading,Proportional Pressure
