Application:

Mobile

Auxiliary mounting:

None

Code title:

Pressure Compensated/Pressure Flow Compensated

Continuous allowable case pressure:

2 bar

Control special features:

None

Controller type:

None

Design code11:

First

Displacement:

19 cubic centimetre per revolution

Drain port size location:

.5625-18 UNF-2B SAE O-Ring Port - Right Side

Eccn:

EAR99

Fluid cleanliness:

18/13

Front mounting:

2 Bolt A

Icc2:

Mobile - OC Piston Pumps

Identification:

Standard

Input shaft:

9 Tooth 16/32 Spline, Shaft Extension 31.8 [1.25]

Input speed rated:

2500 revolutions per minute

Main port size location:

Suction 1.0625-12 UN-2B SAE O-Ring Port; Pressure .875-14 UNF-2B SAE O-Ring Port - Rear

Maximum flow compensator setting:

0 bar

Minimum flow compensator setting:

0 bar

Model Code:

AAYRAA1800CBA00000A0A

Paint:

Primer Per Spec 209-13A

Product height:

5.32

Product height uom:

inch

Product length:

10.1

Product length uom:

inch

Product trade name:

70122 Series

Product weight:

20

Product weight uom:

pound

Product width:

5.5

Product width uom:

inch

Pump special features:

None

Shaft rotation:

Right

Sub brand:

None
