S+R電動升降缸TV-5S技術參數
Type: | TV-5 S |
Adjustment force: | 3,000 N |
Stroke: | 105 mm |
Adjustment speed: | 24 mm/s |
Thrust tube: | 030*4 mm, stainless steel, anti-twist |
Spindle: | Tr 20*4 mm |
Grease: | High temperature grease 100°C |
Fastening: | Eye-eye (stainless steel) |
Paint: | RAL 7031 OS3 |
Gearbox: | NMRV030, i=7.5; IEC 63 B5 |
Painting sheet: | K 005 |
Installation dimensions: | 412 mm |
Motor: | DRN63M2/FF |
Power: | 0.25 KW |
Speed: | 2,755 1/min. |
Frequency: | 50 Hz |
Voltage: | 220/380 VAC |
Rated current: | 1.05/0.61 A |
CE mark: | yes |
Construction specification: | Europe CE |
Protection type: | IP 55 |
ISO class: | Iso F |
Flange: | B5/ 0140 mm |
Shaft: | 1 1x23 mm |
Terminal box: | 0°，x |
Paint: | RAL 7031 OS3 |
Corr. protection: | yes |
S+R電動升降缸S系列其他常用型號：
S+R TV-5S
S+R TV-5SE
S+R TV-20SP
S+R TV-30SP
S+R TV-50SE
S+R ELECTRIC LIFTING CYLINDER NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于S+R電動升降缸TV-5S的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for S+R products, please feel free to dial 0086-21-3100 6702/ send request email to [email protected] / browse our website:www.www.jguvm.cn.
