SCHROEDER濾芯NZ10技術參數
Specifications | |
Short Description | NZ10 |
Type | Hydraulic and Lube Filters |
Style | Elements |
Series | N |
Material | Excellement@ Z-Media@ (Synthetic) |
Nominal Filter Rating | 10 um |
Connection Type | Seal |
Seal Material | Buna |
Beta Ratio | 1000 |
Efficiency | 0.999 |
Filter Rating - Beta Ratio | 10 |
Operating Pressure [Max] | 10.3 bar/150 psi |
Operating Temperature [Min] | -29 °C/-20 oF |
Operating Temperature [Max] | 107 °C/225 oF |
Weight | 0.27 kg/0.6 Ib |
Use With | Schroeder Filter Housing |
Designation | Single Length |
Dimensions | |
Outer Diameter | 1.8 in /46 mm |
Inner Diameter | 0.8 in /20 mm |
Height | 5.3 in /134 mm |
SCHROEDER濾芯NZ10產品介紹
產品編號 7628678，NZ10，濾芯
Item # 7628678, NZ10, Element
SCHROEDER濾芯N系列其他常用型號：
SCHROEDER N10
SCHROEDER N25
SCHROEDER NM10
SCHROEDER NZ10
SCHROEDER NZ1
SCHROEDER NZ10V
SCHROEDER NZ1V
SCHROEDER NZ25
SCHROEDER NZ3
SCHROEDER NZ25V
SCHROEDER Filter Element NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于SCHROEDER濾芯NZ10的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for SCHROEDER products, please feel free to dial 0086-21-3100 6702/ send request email to [email protected] / browse our website:www.www.jguvm.cn.
