EATON節流閥FCV11-12系列參數介紹
PRODUCT SPECIFICATIONS | |
LEAKAGE | Standard |
SPECIAL FEATURES | None |
MINIMUM FLOW RATE | 0 l/min |
INSTALLATION TYPE | Screw-in Cartridge |
ADJUSTMENT TYPE | Screw |
VALVE TORQUE INTO CAVITY | Aluminum housing - 81–95 Nm; Steel housing - 102–115 Nm |
FLOW RATE | 114 l/min |
PRESSURE RATING | 350 bar |
HOUSING | No |
NUMBER OF HOUSING PORTS | 2 |
SEAL TYPE | Buna-N |
SPOOL SEAL | No |
FLUID COMPATIBILITY | MIL–H–5606, SAE 10, SAE 20, etc |
RECOMMENDED FILTRATION LEVEL | 18/16/13 Microns |
CAVITY | C-12-2 |
NUMBER OF VALVE PORTS | 2 |
FUNCTION | Needle Valve |
MAXIMUM FLOW RATE | 114 l/min |
PORT TYPE | Cartridge Only |
STYLE | Flow Restrictor |
VALVE MATERIAL | Steel |
OPERATING TEMPERATURE | -40°C to +120°C |
APPLICATION | Harvesters, refuse haulers, mobile and industrial applications |
EATON節流閥FCV11-12系列其他常用型號：
EATON FCV11-12-S-0-NV
EATON FCV11-12-K-0-NV
EATON FCV11-12-S-A12T-NV
EATON Proportional valve NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于EATON節流閥FCV11-12-S-0-NV的疑問，請隨時與我們電聯，（021-3100 6702），我們將盡全力解決您的問題。
If you have any question for EATON products, please feel free to dial 0086-21-3100 6702/ send request email to [email protected] / browse our website: www.www.jguvm.cn.
EATON節流閥FCV11-12-S-0-NV選型及介紹
