Weight

11.4 kg

Size

280 mm

Motor size

84

Rotor surface

Painted black

Electronics housing material

Die-cast aluminum

Impeller material

Sheet aluminum

Support plate material

Sheet steel, galvanized

Support bracket material

Steel, painted black

Inlet nozzle material

Sheet steel, galvanized

Number of blades

7

Direction of rotation

Clockwise, viewed toward rotor

Degree of protection

IP54

Insulation class

B

Moisture (F) / Environmental (H) protection class

H1

Installation position

Shaft horizontal or rotor on bottom; rotor on top on request

Condensation drainage holes

On rotor side

Mode

S1

Motor bearing

Ball bearing

Technical features

- Output 10 VDC, max. 10 mA
- Output 20 VDC, max. 50 mA
- Output for slave 0-10 V
- Input for sensor 0-10 V or 4-20 mA
- External 24 V input
- Alarm relay
- Power limiter
- Motor current limitation
- RS-485 MODBUS-RTU
- Soft start
- Control input 0-10 VDC / PWM
- Control interface with SELV potential safely disconnected from the mains
- Thermal overload protection for electronics/motor
- Line undervoltage / phase failure detection

Touch current according to IEC 60990

<= 3.5 mA

Electrical hookup

Terminal box

Motor protection

Thermal overload protector (TOP) internally connected

Protection clas

I

Conformity with standards

EN 61800-5-1; CE

Approval

UL 1004-7 + 60730-1; EAC; CCC; CSA C22.2 No. 77 + CAN/CSA E60730-1
