Frame

56C

Frame Material

Steel

Frequency

50.00 Hz

Output @ Frequency

1.000 HP @ 50 HZ

Phase

3

Synchronous Speed @ Frequency

1500 RPM @ 50 HZ

Voltage @ Frequency

440.0 V @ 50 HZ
220.0 V @ 50 HZ
380.0 V @ 50 HZ

Haz Area Class and Group

CLI GP D; CLII GP F,G

Haz Area Division

Division I

Agency Approvals

UL
CSA

Ambient Temperature

40 °C

Auxillary Box

No Auxillary Box

Auxillary Box Lead Termination

None

Base Indicator

Rigid

Bearing Grease Type

Polyrex EM (-20F +300F)

Blower

None

Current @ Voltage

1.800 A @ 440.0 V
2.100 A @ 380.0 V
3.600 A @ 220.0 V

Design Code

B

Drip Cover

No Drip Cover

Duty Rating

CONT

Efficiency @ 100% Load

74.0%

Electrically Isolated Bearing

Not Electrically Isolated

Feedback Device

NO FEEDBACK

High Voltage Full Load Amps

1.8 a

Front Face Code

Standard

Front Shaft Indicator

None

Heater Indicator

No Heater

Insulation Class

B

Inverter Code

Not Inverter

KVA Code

K

Lifting Lugs

No Lifting Lugs

Locked Bearing Indicator

No Locked Bearing

Motor Lead Exit

Ko Box

Motor Lead Termination

Flying Leads

Motor Lead Quantity/Wire Size

12 @ 18 AWG

Motor Type

3432M

Mounting Arrangement

F1

Number of Poles

4

Overall Length

15.22 IN

Power Factor

76

Product Family

Hazardous Location Motor

Pulley End Bearing Type

Ball

Pulley Face Code

C-Face

Pulley Shaft Indicator

Standard

Rodent Screen

None

RoHS Status

ROHS COMPLIANT

Service Factor

1

Shaft Diameter

0.625 IN

Shaft Extension Location

Pulley End

Shaft Ground Indicator

No Shaft Grounding

Shaft Rotation

Reversible

Shaft Slinger Indicator

No Slinger

Speed

1425 rpm

Speed Code

Single Speed

Motor Standards

NEMA

Starting Method

Direct on line

Thermal Device - Bearing

None

Thermal Device - Winding

Normally Closed Thermostat

Vibration Sensor Indicator

No Vibration Sensor

Winding Thermal 1

None

Winding Thermal 2

None

Haz Area Temp Code

T3C
