Mass

3 kg

Size

300 mm

Surface of rotor

Coated in black

Material of terminal box

ABS plastic, black

Material of impeller

PP plastic

Material of guard grille

Steel, phosphated and coated in black plastic

Number of blades

5

Direction of air flow

"V"

Direction of rotation

Counter-clockwise, seen on rotor

Type of protection

IP 44; Depending on installation and position

Insulation class

"B"

Humidity class

F1-2

Max. permissible ambient motor temp. (transp./ storage)

+ 80 °C

Min. permissible ambient motor temp. (transp./storage)

- 40 °C

Mounting position

Any

Condensate discharge holes

None

Operation mode

S1

Motor bearing

Ball bearing

Touch current acc. IEC 60990 (measuring network Fig. 4, TN system)

< 0.75 mA

Electrical leads

Via terminal box, integrated capacitor connected via terminal box

Motor protection

Thermal overload protector (TOP) wired internally

Cable exit

Variable

Protection class

I (if protective earth is connected by customer)

Product conforming to standard

EN 60335-1; CE

Approval

CCC
