DAYTON電機2M509A產品參數
Specification | |
Item | DC Permanent Magnet Motor |
Motor Application | Variable Speed |
Motor Design | DC Permanent Magnet |
HP | 1/3 |
Motor Enclosure Design | Totally Enclosed Fan-Cooled |
Nameplate RPM | 1750 |
Voltage | 90VDC |
Full Load Amps | 3.5 |
Frame | 56C |
Motor Mounting Type | Face/Base |
Motor Thermal Protection | None |
Ins. Class | F |
Bearings | Ball |
Max. Ambient Temp | 40 Degrees C |
Rotation | CW/CCW |
Overall Length | 11-5/16" |
Shaft Dia. | 5/8" |
Shaft Length | 1-7/8" |
Features | 3/8" Diameter Hole 1/2" Deep, Drilled On Opposite Drive Shaft to Accommodate Tach Mounting Kit, Removable Base, #10-32 Adapter |
Standards | UL Recognized (E47479) |
DAYTON電機2M509A產品介紹
永磁電機設計用于恒定或遞減鏈應用中的速度控制器或NEMA K 600型電源。
Permanent magnet motor is designed for use with speed controls or NEMA Type K DC power supplies on constant or diminishing torque applications.
DAYTON電機2M509A其他常見型號：
DAYTON 3XE19
DAYTON 3XE20
DAYTON 4Z529
DAYTON 4Z144
DAYTON 3LCH7
DAYTON 6MK99
DAYTON 6ML04
DAYTON 4Z525
DAYTON 6ML01
DAYTON 2M168A
DAYTON DC Permanent Magnet Motor NEW + ORIGINAL+ ONE YEAR WARRANTY
