supply voltage max

480 V

network number of phases

Three phase

continuous stall current

1.4 A

maximum continuous power

0.45 W

maximum current Irms

6.2 A for LXM15LD13M3
5.4 A for LXM05AD10F1
5.4 A for LXM05CU70M2
5.4 A for LXM05AD10M2
5.4 A for LXM05AD10M3X
5.4 A for LXM05BD10F1
5.4 A for LXM05BD10M2
5.4 A for LXM05BD10M3X
5.4 A for LXM05CD10F1
5.4 A for LXM05CD10M2
5.4 A for LXM05CD10M3X
5.4 A for LXM32.U90M2
4.5 A for LXM32.U45M2

maximum permanent current

5.4 A

switching frequency

8 kHz

second shaft

Without second shaft end

shaft diameter

9 mm

shaft length

20 mm

feedback type

Multiturn SinCos Hiperface

holding torque

0.8 N.m holding brake

motor flange size

55 mm

number of motor stacks

1

torque constant

0.36 N.m/A at 120 °C

back emf constant

22 V/krpm at 120 °C

number of motor poles

6

rotor inertia

0.0803 kg.cm2

stator resistance

12.2 Ohm at 20 °C

stator inductance

20.8 mH at 20 °C

stator electrical time constant

1.7 ms at 20 °C

maximum radial force Fr

170 N at 8000 rpm
180 N at 7000 rpm
190 N at 6000 rpm
200 N at 5000 rpm
220 N at 4000 rpm
240 N at 3000 rpm
270 N at 2000 rpm
340 N at 1000 rpm

maximum axial force Fa

0.2 x Fr

brake pull-in power

10 W

type of cooling

Natural convection

length

159 mm

centring collar diameter

40 mm

centring collar depth

2 mm

number of mounting holes

4

mounting holes diameter

5.5 mm

circle diameter of the mounting holes

63 mm

net weight

1.3 kg
