For motors

DR71-132

Supply voltage

DC7-30V  VB

Max. current consumption

140mA RMS  Iin

Max. pulse frequency

200kHz  Fmax

Periods per revolution

2048  A,B

Output amplitude per track

1 Vss

Signal output

Sin/cos

Outout current per track

10 mA RMS  I out

Mark space ratio

Sin/cos

Phase angle A:B

90°±3°

Scanning code

Gray code

Single-turn resolution

4096 increments / revolution

Muti-turn resolution

4096 revolutions

Data transfer

synchronous-serial

Serial data output

Driver according to EIA RS- 485

Serial clock input

Optocoupler, recommended driver to EIA RS-485

Clock rate

Permitted range: 100 - 2000 kHz (max. 100 m cable length with 300 kHz)

Clock-pulse space period

12- 30 μS

Data memory

1920 bytes

Vibration resustance

≤100m/s2

Shock resistance

≤1000m/s2

Maximum speed

6000 rpm  n max

mass

0.4 kg  m

Degree of protection

IP66

Ambient temperature

-20℃ to +60℃

Connection

Terminal strip in pluggable connection cover
