For motors

DT71 - DV132S, CT71 - CV132S

Supply voltage

DC7-12V  VB

Max. current consumption

130 mA RMs  Iin

Max. pulse frequency

200 kHz  Fmax

Periods per revolution

1024  A,B

Output amplitude per track

1 Vss

Signal output

Sin/cos

Outout current per track

10 mA RMS  I out

Mark space ratio

Sin/cos

Phase angle A:B

90°

Scanning code

Binary code

Single-turn resolution

32768 increments / revolution

Muti-turn resolution

4096 revolutions

Data transfer

RS485

Serial data output

Driver according to EIA RS 485

Serial clock input

Optocoupler, recommended driver to EIA RS-485

Data memory

1792 bytes

Vibration resustance

≤200 m/s2

Shock resistance

≤1000 m/s2

Maximum speed

6000 rpm  n max

Mass

0.3 kg  m

Degree of protection

IP65

Ambient temperature

-20℃ to +60℃

Connection

M23 12-pole
