Voltage Gradient No Load

64 (PECK)/1000RPM

Max. Motor EMF

380 Line-Line Volts

Max. Speed

6000 RPM

Continuous Stall Torque TENV

6.8 Nm  60 Ib-in

(Size 300 X 300 x 12 mm)
Cont. Stall Torque when fitted to Heatsink
(Size12x12X0.5in)

7.5 Nm

66  Ib-in

Peak Stall Torque

22 Nm  190  Ib-in

Continuous Stall Current rms (110)K

9.1 Amps

Rotor Polar Moment of Inertia
(Inclusive of Resolver Inertia)

5.1 kgcm2
0.0045 Ib-in sec2

Max. Current ( Peak )

48 Amps

Cogging Torque

0.17 Nm   1.5 Ib-in

Torque Constant Kt

0.75 Nm/Amp  6.6 Ib-in/Amp

Resistance Line-Line

0.9 Ohms

Inductance Line-line

6.7 MilliHenrys

THERMAL Insulation Class

F

Max. Ambient Temperature

40°C   104°F

Thermal Time Constant

45 Minutes

Thermal Resistance

0.64 °C/Watt   1.15 °F/Watt

Static Friction Torque

0.066 Nm  0.58 |b

Motor Weight

9 kg  20 Ib
