GENERAL

Voltage Gradient No Load

38 Volts/1000RPM

Max. Terminal Voltage

140 Volts

Max. Speed

3700 RPM

Continuous Stall Torque TENV

3.0 Nm   26 lb- in

Continuous Stall Torque Blower Cooled

5.5 Nm   49 lb- in

Continuous Stall Current TENNV

8.6 Amps

Armature Polar Moment of Inertia

0.0017 Kgm2   0.015 lb- in Sec2

Torque Constant KT

0.35 Nm/Amp   3.1 lb- in/Amp

Voltage Constant KV

0.35 Volts Sec Rad -1

Peak Stall Torque

14 Nm   124 lb- in

Current at Peak Torque

47 Amps

Theoretical Acceleration at Peak Torque

8200 Rad/Sec2

Winding

Armature Resistance Less Brushes

0.82 Ohms

Armature Inductance

6.5 Millihenrys

Mechanical Time Constant

15 Milliseconds

Thermal

Insulation Class

F

Max. Ambient Temperature

40 (104) °C (°F)

Thermal Time Constant

50 Minutes

Mechanical

Static Friction Torque

0.15 Nm   1.3 lb- in

Motor Weight

7.3 Kg   16 lb
