Supply voltage Vop

10.30VDC土10 9%0

Current consumption

<10mA

Operating temperature

- 10..+ 60°C

Storage temperature

- 20..+ 70 °C

Electrical connection

screw terminals

Mounting

35 mm DIN rail attachment

Protection class (IEC 144)

IP 50, connections IP 00

Vibrostability

50 m/s2 acc. to IEC 068-2-6

Inputs

Amplitude thresholds

<2Vand>8VorNAMUR

Active edge

positive or NAMUR

Pulse shape

random (squarewave 1:1 for max. frequency)

Input resistance

approx. 5 kΩ

Count input

Min. pulse duration

>100us(5kHz),17ms(30Hz)

Max. counting frequency

5kHzor30Hz

Control input

Reset

- external pulse, pulse length > 17 ms
- by switching the supply voltage off and on (start-up reset)

Output

Signal type

PNP

Signal duration

Ordering code 0 651 109, 0.2..1 ms or 20.. 100 ms
Ordering code 0651 114. 1.20 msor 100 ms ... 2s

Switching voltage

approx. Vop

Switching current

100 mA
