Homologation

PN

Reduced flow coefficient

Setting range

CE - UKCA

60

0,83

0,3 - 60,0 bar

EAC

60

0,83

0,3 - 60,0 bar

ATEX Ex h II 2 Gb - UKEX

60

0,83

0,3 - 60,0 bar

ATEX Ex h II 2 Db - UKEX (1)

60

0,83

0,3 - 60,0 bar

ASME XIII - CRN (Canada)

60

0,629

1,0 - 60,0 bar

SELO - TSG

60

0,629

1,0 - 60,0 bar

CONFIGURATION

Material

Brass

Mixed Brass-Stainless steel

Stainless steel

Model

Con ghiera

Con ghiera

Con ghiera

With ring nut

With ring nut

With ring nut

Senza Ghiera

Senza Ghiera

Senza Ghiera

Without ring nut

Without ring nut

Without ring nut

Con leva

Con leva

Con leva

With lever

With lever

With lever

/

/

Con apertura pneumatica

/

/

With pneumatic opening

/

/

Pneumatica con sensore

/

/

Pneumatic with sensor

Seal System

N.B.R. (Std) -10 / + 100 °C

N.B.R. (Std) -10 / + 100 °C

N.B.R. (Std) -10 / + 100 °C

E.P.D.M. -50 / + 150 °C

E.P.D.M. -50 / + 150 °C

E.P.D.M. -50 / + 150 °C

VITON -20 / +200 °C

VITON -20 / +200 °C

VITON -20 / +200 °C

SILICONE -60 / +200 °C

SILICONE -60 / +200 °C

SILICONE -60 / +200 °C

PTFE -196 / +250 °C

PTFE -196 / +250 °C

PTFE -196 / +250 °C

KALREZ -20 / +250 °C

KALREZ -20 / +250 °C

KALREZ -20 / +275 °C

/

Metal -196 / +250 °C

Metal -196 / +450 °C

Inlet Connection

G.1" - 1"1/4 ISO228

G.1" - 1"1/4 ISO228

G.1" - 1"1/4 ISO228

G.1" - 1"1/4 ISO228 F

G.1" - 1"1/4 ISO228 F

G.1" - 1"1/4 ISO228 F

R.1" - 1"1/4 EN10226

R.1" - 1"1/4 EN10226

R.1" - 1"1/4 EN10226

1" - 1"1/4 NPT

1" - 1"1/4 NPT

1" - 1"1/4 NPT

/

1" - 1"1/2 Tri Clamp

1" - 1"1/2 Tri Clamp

/

DN25-32-40 DIN405-11851

DN25-32-40 DIN405-11851

/

DN20-25-32 PN16-40

DN25-32 PN16-40

/

1" - 1"1/2 150-300 lb

1" - 1"1/2 150-300 lb

Outlet Connection

G.1"1/4 ISO228

G.1"1/4 ISO228

G.1"1/4 ISO228

/

1"1/2 Tri Clamp

1"1/2 Tri Clamp

/

DN25-32-40 DIN405-11851

DN25-32-40 DIN405-11851

/

DN32-40 PN16-40

DN32-40 PN16-40

/

1"1/4 - 1"1/2 - 2" 150-300 lb

1"1/4 - 1"1/2 - 2" 150-300 lb

/

/

/

/

/

/
