Digital inputs

Number

12

Voltage

-3 ... 30 V

Low level

-3 ... 5 V

High level

15 ... 30 V

Power consumption at 24 V DC, typ.

3.5 mA

Delay time L→H, typ.

50 μs

Delay time H→L, typ.

150 μs

Digital I/O

Number of bidirectional, not potential-free inputs

8

As input

Voltage

-3 ... 30 V

Low level

-3 ... 5 V

High level

15 ... 30 V

Power consumption at 24 V DC, typ.

3.5 mA

Delay time L→H

5 μs

Delay time H→L

50 μs

As output

Continuous short-circuit proof

Yes

Voltage

DC 24 V

Load current per digital output, max.

500 mA

Delay time L→H, typ./ max.

150 μs / 400 μs

Delay time H→L, typ./ max.

75 μs / 100 μs

Electrical data

Electronics power supply

DC 24 V (20.4 ... 28.8 V)

Max. power consumption 5)

1.0 A

Power loss, max.

24 W

Protection, max.

20 A

Communication

Communication

PROFINET, EtherNet/IP

Environmental conditions

Installation altitude

2,000 m (6,561.68 ft)

Ambient temperature during

Operation

0 ... 55 °C (32 ... 131 °F)

Storage

-25 ... 55 °C (-13 ... 131 °F)

Transport

-40 ... 70 °C (-40 ... 158 °F)

Relative humidity during

Transport, max.

95 % at 40 °C (104 °F)

Connections

PE connection

1 (M5 screw)

Supply voltage, max.

2.5 mm2 (AWG 14)

Digital inputs, max.

1.5 mm2 (AWG 16)

Digital inputs/outputs, max.

1.5 mm2 (AWG 16)

DRIVE-CLiQ

4

PROFINET

2

RS232

1

Ethernet

1

24 V

1

Measuring sockets

3

Number of slots

Flash card

1

for option modules

1

Mechanical data

Net weight

2.20 kg (4.85 lb)

Dimensions

Width

50.0 mm (1.97 in)

Height

300.0 mm (11.81 in)

Depth

226.0 mm (8.90 in)

Standards

Compliance with standards

CE, KC, cULus, EAC, C-Tick (RCM)
