Power supply

Power supply 24 V~

+20%, 50...60 Hz

Power supply 24 V=

-10%.. .20%

Power consumption

4.9 W/8.7 VA

Parameters

Running time")

35/60/120 s

Angle of rotation

90*

Response bme

200 ms

Power cable

1.2 m,5x 0.5 mm2

Positioner

Positioning signal y

0...10V R> 100 kQ

Posilional feedback signal

0...10 V; load> 10 kQ

Starting point Uo

0Vor 10 V

Contral span oU

10 V

Switching range Xgh

200 mV

Ambient conditions

Temperature of medium2)

Max. 100 °C

Admissible ambient temperature

–10...55 °C

Admissible ambient humidity

5...95% rh, no condensation

Construction

Fitting

Vertically upright to horizontal, not upside down

Weight

0.7 kg

Housing

Lower section black, upper section yellow

Housing material

Fire-retardant plastic

Standards and directives

Type of protection

IP54 as per EN 60529

Protection class

III as per IEC 60730
