Nominal Current (RMS) at 50°C

8A
12A
16A
20A

Frequency

50Hz
60Hz

Motor Connection

1

Control Technology

analog

Motor control type

phase cutting

Case IP Grade

IP55
IP00

Conforms to the following standards

Standard EN 61800-3 (directive 2004/108 CE)
Standard EN 50178 (directive 2006/95 CE)
Standard EN 60204-1 (directive 2006/95 CE)
Connectable into IT-TT-TN systems

Display and settings

rotary switches with 13 stable positions signaling leds

Control Function

proportional master (P)
slave

Number of working parameter set

1
2

Control Parameters

set-point
2 set-point on request
minimum speed limit
cut-off
maximum speed limit

Special Features

direct / reverse mode selection

commands analog input

4

Analog input type

4-20mA
0-5Vdc
0-10Vdc
NTC 10KOhm 25°C

Transducer type

4...20mA
0°C...+70°C
0,5...4,5Vdc

ON/OFF inputs number

1

Logic inputs working modes

(SP) second set-point

Auxiliary power supply

5,0 Volt (Vrr) stabilized
10,0 Volt (Vrr) stabilized
20-24 Volt ±10%

0-10Vdc programmable analog outputs

1

Slave type PWM Command

1

Protections

power supply overvoltages
transient suppressors on analog signal
overcurrent protection on current signal
input lines insulated from power supply voltage

Work temperature

-10°C...+50°C

Storage temperature

-20°C...+80°C
