fixing collar material

Metal

terminals description ISO n°1

(11-12)NC

protective treatment

TC

operator position information

All positions

operator profile

Standard handle
Handle in the center
Handle in the center, 1 C/O, snap action
Dead man’s handle, 1 NC + 1 NO, slow-break
Dead man’s handle, 1 NO + 1 NO, slow-break
Handle, 1 NC + 1 NO
Handle, 1 NO + 1 NO

control station composition

1 flush push-button
1 projecting push-button

notch per direction

1…3 notches at 12°-24°-36° for each direction
1…5 notches at 12°-18°-24°-30°-36° for each direction

adaptation for potentiometer

Without adaptation nor potentiometer
With adaptation, without potentiometer
With adaptation and potentiometer

operator direction information

2 to 6 directions

positive opening

Slow break, double-break contactswith positive opening operation

connections - terminals

Captive screw clamp terminals, <= 2 x 1.5 mm2 with cable end
Captive screw clamp terminals, <= 1 x 2.5 mm2 without cable end
Captive screw clamp terminals, >= 1 x 0.5 mm2

tightening torque

0.8…1.2 N.m conforming to EN 60947-1

shape of screw head

Cross compatible with Philips no 1 screwdriver
Cross compatible with pozidriv No 1 screwdriver
Slotted compatible with flat ? 4 mm screwdriver
Slotted compatible with flat ? 5.5 mm screwdriver

contacts material

Silver alloy (Ag/Ni)

short-circuit protection

10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1

contact block name

ZB2BE102

contacts type and composition

1 NC

[Ith] conventional free air thermal current

10 A conforming to EN/IEC 60947-5-1
10 A conforming to CSA C22.2 No 14

[Ui] rated insulation voltage

500 V (pollution degree 3) conforming to EN 60947-1

[Uimp] rated impulse withstand voltage

6 kV EN 60947-1

[Ie] rated operational current

0.1 A at 250 V, DC-13, R300 conforming to EN/IEC 60947-5-1
0.22 A at 125 V, DC-13, R300 conforming to EN/IEC 60947-5-1

electrical reliability

Λ < 10exp(-6) at 5 V, 1 mA in clean environment conforming to EN/IEC 60947-5-4
Λ < 10exp(-8) at 17 V, 5 mA in clean environment conforming to EN/IEC 60947-5-4
