Pipe Threads

Rc 1/4, 3/8, 1/2 Taper(F)

- Standard

BSP / NPT

- Optional

Body Material

Al. Alloy die-cast

Filter Element Size

5, 25, 40 micron.

Filter Element Material

Plastic (Polycarbonate)

- Standard

Sintered Bronze

- Optional

Filter Bowl Material

Al. Alloy Metal

- Standard

Maximum Inlet Pressure

with Metal Bowl Manual Drain

: 250 psig (17.5 bar)

with Metal Bowl Automatic Drain

: 150 psig (10.5 bar)

Maximum Operating
Temperature (ambient)

80° C

Standard nominal flow rate at 10bar (150 psi). Inlet Pressure 6 bar(87 psi) set press. and a drop of 1bar(14.5 psi) from set

55 scfm (26 dm3/sec) CV (1.04)

Drain

Manual

- Standard

Regulator Type

Relieving

- Standard

Non - Relieving

- Optional

Pressure Adjustment

Hand wheel

- Standard

Regulated secondary outlet
pressure (spring range) and
recommended Pressure gauge
ranges available in kg/cm2

Spring Range psi (bar)

Gauge Range psi (bar)

1

1-10 psi (0.07 to 0.70)

0-15 psi (0-1)

2

3-30 psi (0.21 to 2.10)

0-30 psi (0-2.5)

3

5-50 psi (0.35 to 3.50)

0-60 psi (0-4.0)

4

7.5-75 psi (0.50 to 5.00)

0-100 psi (0-7.0)

5

10-100 psi (0.70 to 7.00)

0-150 psi (0-10.0)

Gauge size

50 mm (Dial Size)

Gauge Port size

Rc 1/4

Gauge connection

Back

Mounting Bracket

Optional

Panel mounting

Possible - Optional

Pressure Gauge (scale)

Kg/cm2 (PSI)

- Standard (For Domestic Market)

Bar (PSI)

- Standard (Export)
