Product Family

3000 Series

Band

C-Band

LO Type

PLL

# of onboard LOs

Single-band

LO Stability

+/- 2 kHz

Noise Figure

20 K

Input Frequency - Band 1

C-Band: 3.40 - 4.20 GHz

Output Frequency 1

L-Band: 950 - 1750 MHz

RF SPECIFICATIONS

LO Frequency 1

5.15 GHz

Phase Noise @ 1KHz offset

-80 dBc/Hz

Phase Noise @ 10KHz offset

-85 dBc/Hz

Phase Noise @ 100KHz offset

-95 dBc/Hz

Conversion Gain

62 dB typ

Gain Variation over operating band

≤ 6.0 dB p-p

Input VSWR

2.2 : 1

Output VSWR

2.5 : 1

Output P1dB compression point

9 dBm

ELECTRICAL SPECIFICATIONS

Power Requirements

12 - 24 V

Current Drain

250 mA

INTERFACE SPECIFICATIONS

RF Input Connector

CPR 229G waveguide grooved

RF Output Connector

Type-N

M & C SPECIFICATIONS

LED Indicators

None

ENVIRONMENTAL SPECIFICATIONS

Temperature - Operational

-40 to +60°C

Temperature - Storage

-40 to +80°C

PHYSICAL SPECIFICATIONS

Dimensions (L x W x H)

145 x 70 x 99 mm

Weight

500 g
